18 TO 45 GHZ

Wideband 1 Watt Amplifiers

For High-Frequency Test Applications

Easy to Use

Single positive supply voltage design
Wide supply voltage range, 10V to 15V
2.92 or 2.4mm connectors available
Optional P_SAT control pin
Available with and without heatsink

Robust Design

Built-in over-voltage and reverse voltage protection
Internal voltage regulation and sequencing

In Stock!

MODEL	FREQ. RANGE (GHz)	GAIN (dB)	P_SAT (dBm)	OIP3 (dBm)	PRICE (ea.)
ZVE-453+	18-45	33	+29	+37	$5095
ZVE-453G+	18-45	41	+28	+39	$5095
ZVE-453HP+	18-45	39	+31	+40	$5795

All of the models listed above come with an attached heatsink. To purchase amplifiers without heatsinks, use the following links: ZVE-453X+, ZVE-453GX+, and ZVE-453HPX+.
